One stop shopping Exhaust Camshaft Adjuster A2710501500 for Mercedes-Benz M271 Series Engine

Standard Hydraulic Exhaust Camshaft Adjuster for Bulk Wholesale

100% OEM Exact Fit, Direct Bolt-On Installation Without Modification

Full Compatible Vehicle List

1. C-Class W204: C180, C200, C260 M271
2. E-Class W212: E200, E260 CGI
3. SLK R172: SLK200
4. CLS C218: CLS260
5. GLK X204: GLK200, GLK260

Matching Powertrains

Installation Position

Optimized Heavy-Duty Structural Design

1. Integral quenched alloy steel sprocket: High hardness, anti-abrasion, effectively avoid tooth skip under high-load acceleration
2. Reinforced multi-chamber hydraulic rotor assembly: Multi-layer fluorine rubber internal seals to prevent hydraulic oil leakage and timing drift
3. Precision machined internal spline hub: Tight meshing with exhaust camshaft, no spline wear or timing deviation
4. Standard built-in oil flow channel: Matches original VVT solenoid oil supply pressure for fast timing response
5. Complete pre-assembled adjuster unit, no extra gaskets or adapters required for direct replacement

Core Engine Timing & Emission Control Functions

1. Adjust exhaust valve timing to optimize EGR circulation, reduce nitrogen oxide exhaust and meet emission standards
2. Improve low-speed torque output, eliminate idle shaking and weak low-speed acceleration response
3. Reduce exhaust residual pressure inside cylinders to cut engine pumping loss and lower comprehensive fuel consumption
4. Stabilize cold start operation, eliminate cold startup rattling noise and prolong timing chain service life
5. Coordinate with intake VVT system to balance power output and fuel economy in full speed range

Common Solvable Vehicle Faults

• Obvious rattling noise from engine front within 3~5 seconds after cold ignition
• Unstable idle speed with severe body vibration when stopping
• Engine fault light on dashboard, trouble code P0014/P0017 stored
• Slow acceleration, insufficient overtaking power
• Fuel consumption obviously higher than normal standard
• Multiple cranks needed to complete cold engine startup

Brief Step-by-Step Installation Guide

Required Tools

1. Park vehicle on flat ground, wait for engine full cooling to avoid scalding by hot oil and parts.
2. Lift vehicle, remove engine upper decorative cover and drain all engine lubricating oil.
3. Use special timing tools to lock crankshaft and camshaft to fix standard timing position.
4. Disassemble timing chain cover, release timing chain tensioner and remove timing chain.
5. Loosen central fixing bolt of old exhaust camshaft adjuster, take off defective VVT gear from camshaft spline.
6. Clean camshaft spline and hydraulic oil passage to remove sludge and metal wear debris thoroughly.
7. Coat thin assembly lubricant on internal hydraulic cavity of new A2710501500 adjuster, align spline and install on exhaust camshaft.
8. Tighten central bolt to factory specified torque value, reset timing chain and tensioner in sequence.
9. Remove timing locking tools, rotate crankshaft manually twice to confirm no jamming or tooth skipping.
10. Refill matching Mercedes engine oil, start engine and idle for 10 minutes to check abnormal noise; connect diagnostic computer to clear fault codes and complete road test.

Strict Factory Testing & Stable Spot Supply
